TCL 43 Inch P615 4K ANDROID TV

Name

65P615-AP

Product Type

LED UHD Android TV

Backlight Type

DLED

CPU

64-bit A55×4 900MHz~1.1GHz

GPU

Mali470×3 600MHz~800MHz

OS

Android P

UI Style

Android TV UI & TCL TV+ 3.x UI

Launcher HomePages Show

Google Play, Featured Apps, Source, etc.

OSD Language

English, Vietnamese, Thai, Chinese, Russian, Arabic, Traditional Chinese, Indonesian, France, Spanish(Latin America), Farsi, Mongol, Uzbek, Hebrew, Malay, Portuguese, Burmese, etc.

TV System

ATV: PAL/NTSC/SECAM-DK/BG/I/M;DTV: DVB-T/T2

AV System

PAL, NTSC

HDMI&HDCP Version

HDMI1.4 & HDMI2.0, HDCP1.4 & HDCP2.2

HDR

HDR10 Decoding

Power Supply

AC 100V-240V 50/60Hz

Power Consumption (TV On)

160W

Power Consumption (Standby)

≤0.5W

ECO Energy Efficiency

Yes

Certification

CB, Dolby Audio, HDMI;CTS (Google Official Certification), Netflix

Internet Link

2.4GHz Wi-Fi 802.11 b/g/n 2T2R;Ethernet Network (RJ45)

LED Indicator Status

Standby indicator (1-LED, white, Color Gamut;below the middle of the bezel)

Bluetooth Version

Bluetooth 5.0

Panel Supplier

CSOT

Aspect Ratio

16:9

Panel Active Size (inch)

64.5

Display Resolution

3840×2160

Brightness (cd/m2)(typ.)

300 (typ.)

Contrast Ratio

4000:1 (typ.)

Response Time (G to G)

6.5 (typ.)

Viewing Angle (H/V)

178°/178° (typ.)

Life Time(Typ.)

30,000 (typ., 8hrs/day)

Colour

1.07G (8 bit + FRC)

Refresh Rate

60

Carton Dimensions LxWxH (mm)

1645*165*1000

Container Loading – 20 feet (pcs)

94

Container Loading – 40 feet (pcs)

200

Container Loading – 40 feet High (pcs)

200

Net Weight With Stand (Kg)

17.3

Net Weight Without Stand (Kg)

17.2

Gross Weight With Packaging (Kg)

22.9

Micro Dimming

1296 zones

Initial Setup

Yes, for user setting in TV first start-up.

Instant power on

A special standby mode for start-up in shorter time.

Bluetooth

Yes, for external bluetooth speaker/soundbar.

Channels Edit

Yes, for TV channel renaming.

Input Settings

For input source device name choice and edit.

Input Method

T-IME, Gboard, Virtual Remote Keyboard

System Update

Yes

T-Link（CEC）

Yes

PVR/Timeshift

Yes (for DTV programme only)

EPG

Yes (for DTV programme only)

Subtitle

Yes

Parental Control

Yes (for DTV programme only)

Speakers

Integrated Speaker Boxes (Bottom Side)

Audio Power Output (THD=7%)

2 x 12W

Sound mode

Standard, Movie, Music, Voice, Game, Stadium, Personal

TV Placement

Desk Top, Wall Mount

Audio Delay

MS12D/Y

Button Sound

On, Off

Audio only

Yes

Backlight Adjustable

0~100

Operation Manual

English (default)

Remote Control and Batteries

RC901V (with 2 AAA batteries)

Base Stand

Integrated in Package

AC power cord

1 pcs

Screw Size

M4×30

Screw Quantity

4

VESA Mounting

WMB333

VESA Hole Pattern

300×300

Screw Size(Wall-Moun)

M6×12

Screw Quantity(Wall-Mount)

4

Music

MP3, WMA, AC4


JPEG, PNG, BMP

Mutilmedia Video/Audio Decoder

H.265, H.264, MPEG2/4, VC1, VP9

Video Format up to

Up to 4K@60Hz-12bit 4:2:2, 4K@60Hz-8bit 4:4:4

USB Mouse/Key Board

Yes

Google Play Store

Popular apps and games.

YouTube

Android TV version.

Google Play Games

Game platform of Google Play.

Google Play Movies&TV

Watch Google Play Movies & TV on Android TV.

Netflix

Watch TV shows and movies online.

Media center

Video/Music play for USB device.

E-Sticker

Yes

Back Cover

SECC/HIPS
