Description
Technical Specifications
- Manufactured By—————-Havells India Ltd.
- Country Of Origin—————India
- Refrigerant———————–Rotary / R-32
- ISEER——————————5.20
- ODU Noise (dB)——————49 dB
- IDU Noise (dB)——————-34 dB
- Air Flow (m³/h)——————–600 m³/h
- Input Power (W)——————735 W / 300 W
- Cooling Capacity (W)———————3200 W / 1600 W
- Input current (A)—————————–3.23 A /1.86 A
- Power Supply (V / Hz / Phase)———230 V – 50 Hz – 1 Phase
- Electricity Consumption————476 kWh
- ODU Net / Gross Weight (kg)————-22.6 kg / 27.0 kg
- ODU Dimension (L×W×H)—————83.5 cm x 30 cm x 52 cm
- ODU Packing (LxBxH)—————–92.5 cm x 38.3 cm x 56.8 cm
- IDU Net / Gross Weight—————-8.8 kg / 10.9 kg
- IDU Dimensions (LxBxH) as per SOW- Label———-76.5 cm x 30 cm x 20 cm
- IDU Packing (LxBxH)——————-81 cm x 35.5 cm x 27 cm
- IDU Dimension (L×W×H)—————-76.5 cm x 20 cm x 30 cm
- Area Coverage————————-11 m²
- Air Throw Distance———————-5 m
- Operating Voltage Range—————-100 V – 300 V
- Operating Temperature Range———–16 °C ~ 52 °C
- Net Contents————1 N Main Unit, 1 N Remote, 1 N Accessories Kit
& 1 N Instruction Manual
